Scans single and double-sided, color and black and white documents in a single pass at up to 25 ppm‡, all in a space-saving, portable design.
Easily scan documents up to 34” long, receipts and photos through the 20-page capacity auto document feeder.
Wireless scanning to PC‡, cloud services‡, mobile‡ and network destinations plus Micro USB 3.0 interface for local connections.
A 2.8” color Touchscreen display offers one-touch scanning to preset destinations and device settings management. Auto Start Scan allows you to simply drop paper into the feeder to automatically initiate scanning to a predefined profile.
Supports multiple “Scan-to” destinations such as File‡, OCR‡, Email‡, Network Folder, FTP, Mobile Devices‡ and USB flash memory drive to help optimize your business processes.
Dedicated card slot makes scanning plastic cards quick and easy:
Enhances scans with automatic color detection/adjustment, image rotation (PC only), bleed through prevention/background removal, text enhancement, color drop.
Supports Windows, Mac® and Linux® environments and offers TWAIN, WIA, ICA, and SANE drivers‡ .
For customer service, visit us at www.brother-usa.com/support.
Feature | Value |
|---|---|
| Standard Interface | Wireless 802.11 b/g/n,Micro USB 3.0 |
| Mobile Device Compatibility‡ | BrotheriPrintandScan |
| Supported Network Protocols IPv4 | Web Services,SNMPv1/v2c,APIPA (Auto IP),CIFS Client,DNS Resolver,FTP Client and Server,HTTP/HTTPS Server,ICMP,LLMNR Responder,mDNS,SMTP Client,SNTP Client,WINS/NetBIOS Name Resolution |
| Supported Network Protocols IPv6 | Web Services,FTP Client,RA,DNS Resolver,mDNS,LLMNR Responder,SMTP Client,CIFS Client,HTTP/HTTPS Server,ICMPv6,SNTP Client |
| WiFi Certified | Yes |
| Bluetooth Compatibility | No |
| Cloud Services (Brother iPrint&Scan)‡ | OneDrive,Google Drive™,DropBox |
Feature | Value |
|---|---|
| Unit Weight | 3.7 |
| Unit Dimensions | 11.8" x 4.1" x 3.3" |
| Carton Dimensions | 7" x 15" x 9" |
Feature | Value |
|---|---|
| LCD Display | 2.8" |
Feature | Value |
|---|---|
| Automatic Document Feeder Capacity‡ | 20 |
Feature | Value |
|---|---|
| ENERGY STAR Certified | Yes |
| Power Source | 120V AC 60 Hz |
| Product Power Consumption Power Off Ready Scanning Sleep | 0.1W / 4.5W / 9W / 1.6W |
Feature | Value |
|---|---|
| Scan Drivers Included‡ | TWAIN,WIA,ICA,SANE |
| Duplex Scanning | Yes |
| "Scan To" Feature‡ | Email,Cloud Services‡ (Brother iPrint&Scan),Workflow‡ (Brother iPrint&Scan),PC (File, Email, Image, OCR),OCR,File,FTP,USB Memory Stick,Network Folder (CIFS - Windows only),E-mail Server‡ |
| Advanced Scanning Features | Continuous Scan,ADF Auto Deskew,Blank Page Skip,ID Scan‡ |
| Image Sensor | Dual CIS |
| Scan File Formats | TIFF Multi-page,PDF Single-page/Multi-page (Secure PDF, Searchable PDF, PDF/A),Windows Bitmap (BMP),JPEG (JPG),PDF Single-page/Multi-page (PDF/A, High Compression PDF,Portable Network Graphics (PNG),TIFF Single-page/Multi-page (TIF) |
| Duplex Scan Speeds (black & color) (max ipm)‡ | 50 |
| Optical Scan Resolution | up to 600 X 600 dpi |
| Paper Jam Sensor | No |
| Barcode Types Supported | Code 39, Code 128, Codabar, UPC-E, EAN13 / JAN13, QR Code, PDF417, ITF, GS1-128, UPC-A, EAN8 / JAN8, Code 93, Data Matrix |
| Color Dropout | Red,Blue,Green |
| Interpolated Scan Resolution‡ (max. dpi) | Up to 1200 x 1200 dpi |
| Scanner Type | Sheetfed |
| Scanning Capability | Black and White,Color |
| Scanning Modes | 24BitColor;8bitgrayscale;1BitMono |
Feature | Value |
|---|---|
| Plastic Card Thickness | 0.76mm - 1.02mm / Embossed up to 1.24mm |
| Daily Duty Cycle (max. pages)‡ | 1,000 |
Feature | Value |
|---|---|
| Security Functions | TLS/SSL,Setting Lock,Secure Function Lock |
| Wireless Network Security‡ | WEP 64/128 bit,WPA/PSK (TKIP/AES),WPA2-PSK (AES) |
Feature | Value |
|---|---|
| Carton Content | ADS-1700W Scanner, AC Adapter, Quick Setup Guide, Warranty Sheet, and Product Registration Sheet |
| Warranty | 1 Year Limited |
