Fast Scan Speeds in Small Footprint:
Single-pass duplex scanning of color and Black & White documents at speeds up to 35 ppm‡ in a spacesaving, lightweight design ideal for most home office and business environments.
Connect Your Way.
Versatile connection options with built-in wireless, Fast Ethernet or connect locally to a single computer via high-speed USB 2.0.
Support for your Most Secure Information.
Secure scanner access by individual and specific scanning functions; Settings Lock; secure network protocols including SSL, TLS, SFTP.
Easy-to-use and Helps Save Time.
A 2.8" color touchscreen display offers one-touch scanning to preset destinations and device settings management and Auto Start Scan allows you to simply drop paper into the feeder to automatically initiate scanning to a predefined profile.
Compatible with the way you do business.
Supports multiple "Scan-to" destinations: File‡, Image‡, OCR‡, Email, Network, FTP, Mobile Devices‡, USB flash memory drive‡ so you can optimize for your business process.
Handles a variety of documents automatically.
50-page capacity auto document feed with additional page continuous scanning handles multiple media types and paper sizes: legal, long paper, business and plastic ID cards, receipts and photos.
Flexibility to Integrate with Your Business Processes and Systems.
Supports Windows®, Mac® and Linux® environments and TWAIN/SANE/WIA for PC drivers‡.
Optimizes images and text for storage/classification‡.
Enhances scans with automatic color detection/ adjustment, image rotation (PC only), bleed through/background removal, text enhancement, color drop out features and more.
Added Value with Bundled Software.
Suite includes document management, OCR, and business card management programs.
Brother Customer Support.
For customer service, visit us at www.brother-usa.com/support.
Connectivity
Feature | Value |
|---|---|
| Standard Interface | Wireless 802.11 b/g/n,Ethernet,Hi-Speed USB 2.0 |
| Mobile Device Compatibility‡ | BrotheriPrintandScan |
| Industry Specific Certifications | Cerner Certified |
| Supported Network Protocols IPv4 | APIPA (Auto IP),CIFS Client,DHCP,DNS Resolver,HTTP/HTTPS Server,ICMP,LLMNR Responder,mDNS,SMTP Client,SNMPv1/v2c/v3,SNTP Client,Web Services (Print/Scan),WINS/NetBIOS Name Resolution |
| One Push Wireless Setup | Wi-Fi Protected Setup™ |
| Bluetooth Compatibility | N/A |
Dimensions
Feature | Value |
|---|---|
| Unit Weight | 5.8 |
| Unit Dimensions | 11.8" x 5.7" x 7.0 " |
| Carton Dimensions | 16" x 10" x 12" |
General
Feature | Value |
|---|---|
| LCD Display | 2.8" Color Swipe TouchScreen Display |
Paper Handling
Feature | Value |
|---|---|
| Automatic Document Feeder Capacity‡ | 50 |
Power
Feature | Value |
|---|---|
| ENERGY STAR Certified | Yes |
| Power Source | AC Adapter |
| Product Power Consumption Power Off Ready Scanning Sleep | 0.1W Off/6.6W Ready/ 25W Scanning / 1.6W Sleep |
| Operating Environment Humidity | 20% - 80% |
| Operating Environment Temperature | 41°ree;F - 95°ree;F (5°ree;C - 35°ree;C) |
Scan
Feature | Value |
|---|---|
| Scan Drivers Included‡ | TWAIN,WIA,ICA,SANE |
| Duplex Scanning | Yes |
| "Scan To" Feature‡ | Email,Shared Folder,PC (File, Email, Image, OCR),FTP,USB Memory Stick,Network Folder (CIFS - Windows only) |
| Advanced Scanning Features | Continuous Scan,Scan Profiles (up to 25),ADF Auto Deskew |
| Image Sensor | Dual CIS |
| Scan File Formats | JPEG (JPG),PDF Single-page/Multi-page (PDF/A, High Compression PDF,TIFF Single-page/Multi-page (TIF) |
| Duplex Scan Speeds (black & color) (max ipm)‡ | 70 |
| Optical Scan Resolution | Up to 600 x 600 dpi |
| Paper Jam Sensor | No |
| Interpolated Scan Resolution‡ (max. dpi) | Up to 1200 x 1200 dpi |
| Scanner Type | Sheetfed |
| Scanning Capability | Black and White,Color |
| Scanning Modes | 24BitColor;8bitgrayscale;1BitMono |
Document Handling
Feature | Value |
|---|---|
| Plastic Card Thickness | 1.32mm with Emboss - 1.0mm without Emboss |
| Daily Duty Cycle (max. pages)‡ | 3000 |
| Media Types | Plain |
Features
Feature | Value |
|---|---|
| Programmable Shortcut Buttons | 48 |
Security Features
Feature | Value |
|---|---|
| Security Functions | Enterprise Security (802.1x),TLS/SSL,Setting Lock |
| Wireless Network Security‡ | WEP 64/128 bit,WPA/PSK (TKIP/AES),WPA2-PSK (AES) |
| Security Protocols (Wireless) | SMTP-AUTH,SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4),SNMP v3,802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) |
| Security Protocols (Wired) | SMTP-AUTH,SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4),SNMP v3,802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) |
What’s Included
Feature | Value |
|---|---|
| Carton Content | ADS-2700W Scanner, AC Adapter, Quick Setup Guide, Warranty Sheet, and Product Registration Sheet |
| Warranty | 1 Year Limited |
